Optrotech Fiber Fusion Splicer
OPTROTECH Optical fiber fusion splicer is a mini fiber splicing equipment which is compactly designed. easy to carry and operation. It has a vivid exquisite image forming system and high precision image processing technology on fiber alignment which leads to its high proficiency in splicing and low loss. Its beautiful operation interface and body design which conforms to the operation principle of ergonomics greatly improve user experience. It is equipped with a large capacity lithium battery which provides a reliable guarantee for long time fieldwork. In summary, a removable plug large lithium battery capacity, providing a credible guarantee for fieldwork for a long time It is a totally automatic small light and beautiful optical fiber fusion splicer with high performance, high safety, low power consumption and can be easily operated.
- 6 motor Double core align structure, higher success rate of fusion and lower loss
- Reliability design to enhance the ability of shockproof and dustproof
- Low-power design, many functions can be used at the same time, and can still work for a long time
- Small size and light weight can greatly improve work efficiency
- Applicable optical fiber type: SM(652/G.657),MM(G.651),NSDS (G.655),EDF,BIF?UBIF.
Technical Index
- Applicable optical fiber diameter:- cladding diameter-80-150um,coating diameter 125~100um
- Average Fusion splice loss:-0.02dB(SM),0.01dB(MM),0.04dB(DS),0.04dB(NSDS)
- Return Loss :- Better Than 60dB
- Fusion Splice Duration Time:-9sec (typical Mode), 7Sec (Fast Mode)
- Display:-5 inches colorized LCD,
- Power Supply:-11.1V Lithium Battery, 13.5V/5A power adapter
- Alignment:-Core Alignment Cladding Alignment Fine Alignment
- Applicable Optical Fiber Cable Diameter:-2mm,3mm,4mm,6mm
- Applicable Sleeve Length:-60mm,45mm,40mm(FP-03)
- Heating Time:-17s/22s V Groove Fast Heating (customizable)
- Heating Temperature:-Below230C (customizable)
- Automatic Heating:-Automatic Fiber identification & Heating when close cove
